VCH-3212-DI - Ventilation controls

SKU: 1332

Description

Analog ventilation controller
- 0-2500Pa

- 0-10V, 2-10V, 0-20mA or 4-20mA

- Spring connections

- Display shows either pressure or flow rate

- 4 Setpoints

  • Cable length: ø3-10 mm
€316,40
Shipping will be charged at checkout.

Specification
  • Manufacturer
    OJ Electronics

Customer Reviews

Be the first to write a review
0%
(0)
0%
(0)
0%
(0)
0%
(0)
0%
(0)

VCH-3212-DI - Ventilation controls

€316,40

Analog ventilation controller
- 0-2500Pa

- 0-10V, 2-10V, 0-20mA or 4-20mA

- Spring connections

- Display shows either pressure or flow rate

- 4 Setpoints
