NLSW45-3 air flow monitor evaluation unit with SIL1 certification

SKU: 63377SIL1

Description

Universal airflow monitor with Safety Integrity Level 1 (SIL1) in accordance with IEC 61508/IEC61511 (alternatively device with SIL2 certification available)

With switching output suitable for switch cabinet installation

Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

Large measuring range from 0.1 ... 30 m/s, quick and easy commissioning

Example areas of application: Monitoring of heating registers, air curtain systems, butterfly valves, fans, DDC


Operating instructions (German/ English)

Power supply
€310,10
Shipping will be charged at checkout.

Operating instructions EN: Download

Operating instructions EN: Download

Specification

  • Medium
    Gases
  • Device type
    Flow evaluation unit for switch cabinet installation
  • Flow measuring range
    0.1 ... 30 m/s
  • Media temperature
    -25 ... 120°C
  • Display
    LED (voltage & switching point)
  • Switching point
    Stepless adjustment (potentiometer)
  • Protection class evaluation unit
    IP40
  • Special features
    Start-up override 5-60 sec., additional external start-up override
  • Output signal
    Switching output
  • Switching output specification
    1 changer
  • Signal output sensor break
    Relay drops out
  • Signal output Sensor short circuit
    Relay drops out
  • Relay output specification
    1 changer
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Assembly
    DIN rail
  • Power supply
    24 V AC/DC ±5%, 230 V AC ±5%
  • Electrical connection
    Terminal strip
  • Power consumption max
    3 VA
  • Recommended cable cross-section
    2.5 mm²
  • Minimum switching capacity
    10 mA, 5 V DC
  • Ambient temperature
    -20 ... 50°C
  • Certificates
    CE, Type-tested TÜV Nord according to DIN EN 61010-1 2011-07
  • SIL level
    SIL1
  • Country of origin
    Germany
  • Customs tariff number
    90 26 80 20
  • HS Code
    90 26 80
