Evaluation unit air flow monitor NLSW45-6 for environments up to 250°C

SKU: 81504

Description

✅ Air flow monitor with switching output for switch cabinet installation

✅ Safely and reliably monitor hot air flows up to 250°C (monitoring up to 400°C possible with the NLSW45-6.1 evaluation unit)

✅ Sensitive and delicate response behavior

✅ Large measuring range (0.1 ... 30 m/s), quick and easy commissioning

✅ Areas of application: Monitoring of heating coils, drying systems, industrial ovens, granulate dryers, surface technology systems, thermal process technology

Power supply
€197,00
Shipping will be charged at checkout.

Immediately available from stock

Operating instructions EN: Download

Operating instructions EN: Download

Specification
  • Medium
    Gases
  • Device type
    Flow evaluation unit for switch cabinet installation
  • Flow measuring range
    0.1 ... 30 m/s
  • Media temperature
    -20 ... 250°C
  • Display
    LED (voltage & switching point)
  • Switching point
    Stepless adjustment (potentiometer)
  • Protection class evaluation unit
    IP40
  • Special features
    Start-up delay, adjustable, approx. 2 ... 60 s, additional external start-up override
  • Output signal
    Switching output
  • Switching output specification
    1 changer
  • Signal output sensor break
    Relay drops out
  • Signal output Sensor short circuit
    Relay drops out
  • Relay output specification
    1 changer
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing dimensions
    120 mm x 45 mm x 73 mm
  • Assembly
    DIN rail
  • Power supply
    24 V AC/DC ± 5%, 230 V AC ± 5%
  • Electrical connection
    Terminal strip
  • Power consumption max
    3 VA
  • Recommended cable cross-section
    2.5 mm²
  • Current and contact load capacity
    250 VAC, 8 A, 2 kVA
  • Minimum switching capacity
    10 mA, 5 V DC
  • Ambient temperature
    -20 ... 50°C
  • Certificates
    CE
  • Country of origin
    Germany
  • Customs tariff number
    90 26 80 20
  • HS Code
    90 26 80
