Evaluation unit air flow monitor NLSW45-3 SIL1 with analog output

SKU: 1434SIL1/A

Description

✅ Universal airflow monitor with Safety Integrity Level 1 (SIL1) according to IEC 61508/IEC61511 (alternatively device with SIL2 certification available)

✅ With analog output and switching output suitable for switch cabinet installation

✅ Type tested by TÜV NORD in accordance with DIN EN 61010-1: 2011-07

✅ Large measuring range from 0.1 ... 30 m/s, quick and easy commissioning

✅ Example areas of application: HVAC systems, fire and smoke protection systems, industrial and process applications, power plant and energy systems, automotive industry and test benches

Power supply
Signal output
€379,60
Shipping will be charged at checkout.

Immediately available from stock

Technical drawing 2D: Download

Operating instructions EN: Download

Operating instructions EN: Download

Specification
  • Medium
    Gases
  • Device type
    Flow evaluation unit for switch cabinet installation
  • Flow measuring range
    0,1 ... 30.0 m/s
  • Media temperature
    0 ... 90°C
  • Display
    LED (voltage & switching point)
  • Switching point
    Continuously adjustable via potentiometer
  • Protection class evaluation unit
    IP40
  • Special features
    1 analog output selectable (4 ... 20 mA or 0 ... 10V)
  • Output signal
    Switching output, analog output
  • Switching output specification
    1 changer
  • Signal output sensor break
    Relay drops out
  • Signal output Sensor short circuit
    Relay drops out
  • Relay output specification
    1 changer
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Housing material
    Polycarbonate glass fiber reinforced (UL94V-0)
  • Weight
    190 g
  • Housing dimensions
    120 mm x 45 mm x 73 mm
  • Assembly
    DIN rail
  • Power supply
    24 V AC/DC ±5%, 230 V AC ±5%
  • Electrical connection
    Terminal strip
  • Power consumption max
    2,5 VA (24V), <6,4 VA (230V)
  • Recommended cable cross-section
    2.5 mm²
  • Current and contact load capacity
    250 V AC, 4A, 1 kVA / 150W, Electrical service life (at 5 A / 230 V AC): 50,000 switching operations, Electrical service life (at 5 A / 30 V DC): 100,000 switching operations
  • Minimum switching capacity
    100 mA / 5 V DC
  • Ambient temperature
    -20 ... 50°C
  • Certificates
    CE, Type-tested TÜV Nord according to DIN EN 61010-1 2011-07
  • SIL level
    SIL1
  • Country of origin
    Germany
  • Customs tariff number
    90 26 80 20
  • HS Code
    90 26 80
