HumiGuard® HT201 - Humidity and temperature transmitter, industrial transmitter, two-part, high temperature

SKU: 1428/V

Description

✅ Sensors for humidity and temperature in wall version

✅ for industrial transmitters, robust and high accuracy

Transmitter with remote sensor

✅ High temperature sensor, measuring range: -80 ... 200°C

✅ Example area of application: industrial automation, agriculture, food and pharmaceutical logistics, climate and environmental monitoring

Analog output
€714,36
Shipping will be charged at checkout.

Specification
  • Medium
    Air, non-aggressive
  • Device type
    Humidity and temperature transmitter
  • Device type
    Wall-mounted version with two-part, offset probe
  • Temperature measuring range
    -80 ... 200°C
  • Temperature measuring accuracy
    -80 ... 200°C
  • Media temperature
    -80 ... 200°C
  • Measuring range rel. humidity
    0 ... 100% rH
  • Measuring accuracy rel. humidity
    10 ... 90% rF bei 23°C: ±1,5% rF, <10% rF oder >90% rF: ±2% rF, Temperatureinfluss ҂ 23°C: <0,02% rF/K
  • Protection class evaluation unit
    IP65
  • Sensor protection class
    IP65
  • Special features
    Probe up to 200°C, Probe in two parts, Probe: 64 mm probe tube, 1.5 m special Teflon cable, 104 mm probe tip, Ø20 mm probe tube, Ø15 mm probe
  • Output signal
    Analog output, Humidity only, 1x active, Humidity and temperature, 2x active
  • Immersion depth
    max. ~93 mm
  • Process connection
    Duct mounting
  • Housing material
    Ali die casting
  • Material sensor
    Stainless steel
  • Housing material
    Ali die casting
  • Housing dimensions
    80 mm x 75 mm x 57 mm
  • Diameter
    Ø15 mm
  • Power supply
    15 .. 30 V DC
  • Electrical connection
    Cable gland: clamping range Ø3 ... 7mm, screw terminals
  • Power consumption max
    <7 mA
  • Recommended cable cross-section
    max. 1.5 mm²
  • Load resistance
    Voltage output: ≥10 kΩ, Current output: Load, RL (Ω)= ((supply voltage -10 V)/0.02 A) ±50 Ω
  • Response time
    bei v=2 m/s: <10 s
  • Switching differential
    Hyterese: <1% rF
  • Type of sensor element
    FE09, Pt1000 1/3-DIN Kl.B
  • Ambient temperature
    -40 ... 85°C
  • Storage temperature
    -40 ... 85°C
  • Certificates
    CE
  • Country of origin
    Germany
  • Customs tariff number
    90 26 20 20
  • HS Code
    90 26 20
